How to choose BS 5839 compliant fire alarm cable?

A BS <a href="https://chinneelectric.com/knowledge/faq/what-installation-practices-are-essential-to-maintain-bs-<a href="https://chinneelectric.com/knowledge/faq/what-are-the-key-performance-requirements-a-cable-must-meet-to-be-considered-bs-<a href="https://chinneelectric.com/knowledge/faq/what-is-the-difference-between-standard-and-enhanced-fire-resistant-cables-in-a-bs-5839-system/”>5839-1-compliant/”>5839-cable-performance/”>5839 compliant fire alarm cable is a cable designed to maintain circuit integrity under fire conditions as required by BS 5839-1:2017, using low-smoke zero halogen (LSZH) materials to protect life and equipment. Chinne Electric's Toxfree range meets these requirements by passing the fire resistance tests of BS EN 50200 and BS 8434-2, ensuring reliable alarm system operation during evacuation and firefighting.

Explore related solutions on our site: Knowledge hub, What are the key performance requirements a cable must meet to be con…, What is the difference between standard and enhanced fire-resistant c….

Understanding the Life-Safety Imperative

Selecting the correct fire alarm cable is not merely a technical checkbox—it is a legal and moral obligation. In the United Kingdom, the benchmark for fire detection and alarm systems is BS 5839, with Part 1 covering non-domestic premises and Part 6 covering dwellings. Compliance with BS 5839-1:2017 ensures that cables will maintain circuit integrity for a sufficient duration during a fire, allowing detection devices, sounders, and control panels to perform their life-saving functions. Getting this choice wrong can lead to premature system failure, regulatory penalties, and, most critically, loss of life.

At Chinne Electric, we recognise that specifiers and installers face a bewildering array of cable types, armouring options, and fire-performance claims. This guide cuts through the complexity, placing special emphasis on halogen-free, low-smoke Toxfree solutions that meet the most stringent British and European standards while protecting both people and equipment.

Key Takeaways

  • Standard compliance is non-negotiable: All fire alarm cables must conform to BS 5839-1:2017, with fire-resistant cables tested to BS EN 50200 (PH30/PH60/PH120 classification) and, for enhanced applications, BS 8434-2.
  • Standard grade vs. Enhanced grade matters: BS 5839-1 differentiates between “standard” fire-resisting cables (meeting BS EN 50200) and “enhanced” fire-resisting cables (meeting BS 8434-2), which sustain circuit integrity under direct flame and mechanical shock for longer durations.
  • Halogen-free is no longer optional: For public buildings, high-occupancy residential, and confined spaces, low-smoke zero-halogen (LSZH) cables such as Chinne Electric’s Toxfree range are essential to prevent toxic gas inhalation and corrosive damage during evacuation and firefighting operations.
  • Armouring provides added protection: Steel wire armoured (SWA) fire alarm cables offer mechanical protection and are mandatory in areas with high risk of physical damage, provided the fire-resisting properties remain uncompromised.
  • Correct installation is as vital as the cable itself: Even the finest BS 5839-compliant cable will fail if not installed with appropriate fire-rated fixings, glands, and segregation from other services, in accordance with BS 7671 and manufacturer instructions.

What BS 5839-1:2017 Actually Requires from Cables

BS 5839-1:2017, “Fire detection and fire alarm systems for buildings – Part 1: Code of practice for design, installation, commissioning and maintenance of systems in non-domestic premises,” dedicates an entire section (Clause 26) to cables and wiring. The standard does not exist in isolation—it cross-references a hierarchy of cable performance standards that specifiers must understand.

The core requirement is that cables forming part of the fire detection and alarm system must be fire-resisting, not merely flame-retardant. Flame-retardant cables resist the spread of flame along their length; fire-resisting cables go much further—they must continue to function for a defined period while exposed to fire. BS 5839-1 recognises two tiers:

  • Standard fire-resisting cables: Tested to BS EN 50200, which assesses circuit integrity under fire attack at 842°C with mechanical shock. These cables must achieve at least a PH30 classification (30 minutes of survival) for most applications. For unsprinklered buildings or high-risk areas, PH60 or PH120 may be specified.
  • Enhanced fire-resisting cables: Tested to BS 8434-2, which applies a more rigorous test regime including direct flame impingement at 950°C and a water spray test. Enhanced cables are mandated in systems designed to remain operational for longer than 30 minutes, in high-rise buildings, and where evacuation strategies rely on phased or delayed egress.

BS 5839-1, Clause 26.2, also prohibits the use of thermoplastic (PVC) insulated and sheathed cables without fire-resisting properties for any part of the critical signal path. This includes detector circuits, sounder circuits, and interconnections between control panels. Non-fire-resisting cables may only be used on the mains supply side of the control panel, upstream of any protective device.

The Toxfree Advantage: Why Halogen-Free Matters

The term toxfree refers to cables manufactured with low-smoke zero-halogen (LSZH) materials. Traditional PVC cables, when burned, release dense black smoke and hydrogen chloride gas, which combines with moisture to form hydrochloric acid. This toxic cocktail is the leading cause of incapacitation and death in building fires, long before flames reach occupants. Hydrogen chloride also corrodes sensitive electronic equipment, leaving entire buildings economically unrecoverable after even a small fire event.

Chinne Electric’s Toxfree fire alarm cables are engineered with halogen-free insulation and sheathing compounds that:

  • Eliminate halogen acid gas emissions: Compliant with IEC 60754-1 and IEC 60754-2, ensuring zero halogen acid evolution during combustion.
  • Drastically reduce smoke density: Achieving minimum light transmittance values exceeding 60% when tested to IEC 61034-2, compared to PVC cables that often fall below 20%. This preserves visibility for safe evacuation and firefighter ingress.
  • Maintain full circuit integrity: Despite the softer mechanical properties of LSZH compounds compared to PVC, Chinne Electric’s advanced cross-linking and filler technologies ensure the cable meets or exceeds BS EN 50200 PH60 and BS 8434-2 classifications without compromise.
  • Support sustainability goals: Halogen-free cables produce less toxic waste at end-of-life and align with BREEAM and LEED green building credits.

The Construction Products Regulation (CPR) (EU) 305/2011, which remains applicable in Northern Ireland and influences best practice across the UK, classifies cables by their reaction to fire using Euroclasses. Toxfree cables typically achieve a minimum of Class Cca-s1a,d1,a1, placing them in the highest performance bracket for smoke production (s1a), flaming droplets (d1), and acidity (a1). Specifiers should demand third-party test reports confirming these classifications rather than relying on manufacturer claims alone.

Selecting the Right Cable for Each Application

BS 5839-1 does not mandate a single cable type universally. The appropriate selection depends on building height, occupancy type, fire engineering strategy, and installation environment. The following practical framework guides specification:

1. Building Type and Evacuation Strategy

For a single-stage evacuation in a low-rise office building, a standard fire-resisting cable meeting BS EN 50200 PH30 may suffice. However, in high-rise residential towers, hospitals, or care homes where phased evacuation or defend-in-place strategies are employed, enhanced cables tested to BS 8434-2 become mandatory. The additional mechanical robustness under fire conditions ensures that fire telephones, disabled refuge systems, and evacuation alert systems remain operational for extended periods—often 60 to 120 minutes.

2. Mains Supply Cables

BS 5839-1, Clause 26.2(d), states that the mains supply cable to the fire alarm control panel need not be fire-resisting provided it is adequately protected against the effects of fire in the supply route. However, best practice—and many enforcing authority interpretations—favours fire-resisting supply cables, particularly where the supply routes through areas of risk. Chinne Electric recommends Toxfree LSZH SWA cables for mains supply applications where mechanical protection and fire resistance are both desirable.

3. Soft Skin vs. Armoured Construction

The choice between soft-skin and armoured fire alarm cables hinges on installation conditions:

  • Soft-skin cables (e.g., FP200 Gold equivalent Toxfree Standard) are suitable for surface-mounted installation on cable trays, within trunking, or buried in plaster where mechanical damage risk is low. They are easier to terminate and route.
  • Steel wire armoured (SWA) cables (e.g., Toxfree Armoured Fire) are required where cables are buried directly in the ground, exposed to vehicular traffic, installed in areas prone to impact, or where enhanced rodent resistance is needed. The steel wire armour provides mechanical protection but does not contribute to fire resistance—the inner fire-resisting core must independently meet the BS EN 50200 or BS 8434-2 classification.

4. External and Underground Installations

Connecting fire alarm systems between separate buildings or to remote plant rooms often requires cables that withstand moisture, UV exposure, and ground conditions. A Toxfree SWA cable with a UV-stabilised LSZH outer sheath, combined with proper glanding and IP-rated junction boxes, satisfies BS 5839-1 while maintaining the halogen-free integrity of the installation.

Critical Installation Practices That Preserve Compliance

A BS 5839-compliant cable is only as good as its installation. The standard, alongside BS 7671 (the IET Wiring Regulations), imposes specific requirements that installers must follow to avoid creating points of failure:

FAQs

Click a question to reveal the answer.

To comply with BS 5839-1:2017, a fire alarm cable must demonstrate enhanced fire resistance as defined by the standard, typically requiring the cable to maintain circuit integrity when tested in accordance with BS EN 50200 and, for high-risk areas, the more onerous 30-minute flame and water spray test of BS 8434-2. The cable should be rated as ‘standard’ or ‘enhanced’ depending on the anticipated fire duration, and must use low-smoke zero halogen (LSZH) materials to protect occupants and equipment in the event of a fire.
