VV-F H05VV-F
VV-F H05VV-F cable has been specially designed for connecting small home appliances.
Typical applications of VV-F H05VV-F
H05VV-F flexible cables suit small electrical appliances, offering reliable current transmission, mechanical strength, and easy handling in low-voltage domestic or light-duty industrial environments.
H05VV-F flexible cables support fixed installations in furniture, partition walls, and hollow spaces of prefabricated elements, meeting household wiring requirements with flexibility and compliance to European standards.
H05VV-F flexible cables suit light mobile services in indoor applications where frequent flexing and moderate mechanical stress are required for portable devices or temporary power connections.
H05VV-F flexible cables suit small electrical appliances, offering reliable current transmission, mechanical strength, and easy handling in low-voltage domestic or light-duty industrial environments.
H05VV-F flexible cables support fixed installations in furniture, partition walls, and hollow spaces of prefabricated elements, meeting household wiring requirements with flexibility and compliance to European standards.
H05VV-F flexible cables suit light mobile services in indoor applications where frequent flexing and moderate mechanical stress are required for portable devices or temporary power connections.
Technical specifications
Application
TOPFLEX® VV-F H05VV-F cable has been specially designed for connecting small home appliances such as vacuum cleaners, washing machines, refrigerators, etc. It is recommended for household installations and can also be used for light mobile uses. These cables are also suitable for fixed applications in furniture, wall partitions, and in hollow spaces of prefabricated building parts.
Construction
Conductor
Copper, class 5 (flexible).
Insulation
PVC (flexible).
The standard identification according to UNE 21089-1 and HD 308, is the following:
2 x Blue + Brown.
3 G Blue + Brown + Green/Yellow.
4 G Brown + Black + Grey + Green/Yellow.
5 G Brown + Black + Grey + Blue + Green/yellow.
Outer sheath
PVC (flexible).
Grey, white or black are the standard outer sheath colours.
Other colours available on request.
Standards / Compliance
Standards and approvals
- CE.
- SEC.
- HAR.
- AENOR.
- RoHS.
Construction Products Regulation
- Eca.
Top Cable reserves the right to carry out any modification to the data sheets whatsoever without giving previous notice. All renders, specifications and particulars of weights, size and dimensions contained in this documentation is indicative only and shall not be binding on Top Cable.
Characteristics
300/500V
Maximum service temperature: 70ºC.
Maximum short-circuittemperature: 160ºC (max. 5 s).
Minimum service temperature: 5º.
Flame non-propagation according to EN 60332-1 and IEC 60332-1.
Reaction to fire CPR: Eca according to EN 50575.
Reduced halogen emission. Chlorine <15%.
Minimum bending radius: 3 x cable diameter < 12mm. 4 x cable diameter >= 12mm.
Impact resistance: AG2 Medium severity.
Chemical & Oil resistance: Good.
Water resistance: AD5 Jets.
Open Air.
Buried.
In conduit.
Meter by meter marking.
Why choose our VV-F H05VV-F
-
As cable manufacturers, we ensure cost-effective premium quality and lasting performance.
-
Our in-house labs guarantee rigorous cable quality, reliability, and standards compliance.
-
Global cable delivery solutions—expert logistics for seamless supply.
-
Full cable stock, ready for fast delivery- shortest lead times.
-
EPD-certified cables: Sustainable manufacturing for your Scope 3 success.
-
Expert, friendly and professional sales team offering a fast & efficient customer service. Global customers are welcome!
VV-F H05VV-F FAQ FAQs
Click a question to reveal the answer.
Chinne Electric VV-F H05VV-F is engineered for reliable performance in commercial and industrial installations, with documentation aligned to applicable international standards.
Refer to the product technical specifications for cited standards such as IEC, GB/T, or JB/T requirements relevant to cable systems and installation practice.
Typical applications include building electrical systems, industrial plants, infrastructure projects, and MEP installations requiring organized cable routing and long-term maintainability.
Selection should consider load, environment, corrosion protection, fire performance, and installation constraints. Contact Chinne Electric for project-specific guidance.
Chinne Electric supports customized dimensions, finishes, and project documentation for export and compliance requirements.
